systems management

DELL POWER SOLUTIONS | November 2007

Reprinted from

Dell Power Solutions,

Figure 7 lists other example raw commands for generating platform

event messages. The sensor IDs are platform specific. Once the Platform

Event Trap events are generated, administrators can verify them using the

command ipmitool -I open sel list.

Expanding IPMItool remote management with raw commands

Raw commands enable administrators to expand the functionality of

IPMItool and gain powerful remote management capabilities. When com-

bined with the guidelines in the IPMI 2.0 specification and the BMCs of

Dell PowerEdge servers, IPMItool can become an indispensable tool in

enterprise data centers.

Seshadri N. is a Product Group senior engineering analyst in the Dell

Tools and Automation Framework Group. He has a B.E. in Computer Science

from Visvesvaraya Technological University and an M.S. in Software

Systems from the Birla Institute of Technology and Science, Pilani.

Raghavendra Babu is a Product Group test engineer senior analyst on

the Test Engineering team at the Dell Bangalore Development Center. He

has a B.E. in Computer Science and Engineering from Visvesvaraya

Technological University.

QUICK LInKs

IPMI specification:

developer.intel.com/design/servers/ipmi/spec.htm

IPMItool man page:

ipmitool.sourceforge.net/manpage.html

Khobragade, Kalyani. “Exploring the Remote Access

Configuration Utility in Ninth-Generation Dell

PowerEdge Servers.” Dell Power Solutions,

February 2007. DELL.COM/downloads/global/

power/ps1q07-20060359-Khobragade.pdf

Platform event

message

Raw command

Over temperature

raw 0x04 0x02 0x04 0x01 0x01 0x01 0x09 00 00

Over voltage

raw 0x04 0x02 0x04 0x02 0x11 0x01 0x09 00 00

Chassis intrusion

raw 0x04 0x02 0x04 0x05 0x52 0x6f 0x00 00 00

Fan redundancy

lost

raw 0x04 0x02 0x04 0x04 0x30 0x0b 0x01 00 00

Power

redundancy lost

raw 0x04 0x02 0x04 0x08 0x44 0x0b 0x01 00 00

Power supply

failure

raw 0x04 0x02 0x04 0x08 0x44 0x6f 0x01 00 00

Power supply lost

raw 0x04 0x02 0x04 0x08 0x44 0x6f 0x03 00 00

Memory

redundancy lost

raw 0x04 0x02 0x04 0x0c 0x13 0x0b 0x01 00 00

System event

log full

raw 0x04 0x02 0x04 0x10 0x51 0x6f 0x04 00 00

Figure 7. Example raw commands for generating platform event messages
